fc/pc connector singlemode simplex armord fiber optic patch cord

1.RoHS,ISO9001

2.Factory price

3.10 years warrenty

4.sample are available

Inquiry

FC/PC singlemode simplex  armored fiber optic patch cord



Applications
*Lacal Area Networks, Wide Area Network, Cable TV
*Testing Instrument, Active Device Connection
*Fiber Optic Distribution Frame(ODF)
*Fiber to the Home(FTTH)
*elecommunication Network


Specification

Connector

FC

UPC

APC

Insertion Loss

<or=0.2dB

Return Loss

>or=50dB

>or=60dB

Fiber Diameter(mm)

0.9,2.0,3.0

Durability

(1000matings)<0.3dB

Interchanability

<0.2dB

Operating Temperature

 -40C~+85C



Description

*Fiber type: 9/125um(SM), 50/125um(MM-OM2),62.5/125um(MM-OM1),available for OM3
*Cable material: PVC or LSZH
* Length customized, 1M, 2M…..etc.
*All parts are RoHS compliant
*Each patch cord is packaged in a sealed plastic bag with cleaning instructions.
*Hybrid patch cord is available upon request
*Available for pigtails.



Applications
*Lacal Area Networks, Wide Area Network, Cable TV
*Testing Instrument, Active Device Connection
*Fiber Optic Distribution Frame(ODF)
*Fiber to the Home(FTTH)
*elecommunication Network



Ordering Information:

*Connector:LC-MU,FC-SC,FC-LC,FC-ST,SC-LC...others

*U:UPC, A:APC

*SM:Singlemode,  MM6:Multimode 62.5/125um

  MM5:Multimode 50/125, OM3:Multimode OM3

*SX:Simplex, DX:Dulex

*Fiber diameter:0.9,2.0,3.0

*Length :1M,2M,3M,4M...Others.

*P:PVC,L:LSZH.
