12 Cores FC/UPC Singlemode 0.9 Ribbon Patch cord /Pigtail 1.5M
1.Low insertion loss, high return loss
2.Good reliability and stability
3.Compliant with the standard of GR-1221
1.Low insertion loss, high return loss
2.Good reliability and stability
3.Compliant with the standard of GR-1221
FC/UPC 12 Cores Singlemode 0.9 Ribbon Patch cord /Pigtail 1.5M
Application:
*Optical CATV
*Optical fiber communication system
*Local Area Network
*Testing equipment
Feature:
1.Low insertion loss, high return loss
2.Good reliability and stability
3.Compliant with the standard of GR-1221
4.Various interfaces: FC, SC, ST, LC, MTRJ, MU, MPO etc
5.Core of cable: 4, 6, 8, 12, 24…
6.Polishing type: PC, UPC, APC
7.Color:Orange,yellow,red..etc.
Specification:
Product | 12 Cores Buldle pitail | |
FC/UPC-SM-0.9-1.5M | ||
Color | Insertion loss(dB) | Return loss(dB) |
Blue | 0.07 | 52.1 |
Orange | 0.17 | 53.8 |
Green | 0.17 | 54.9 |
Brown | 0.17 | 53.2 |
Gray | 0.14 | 53.2 |
White | 0.07 | 52.6 |
Red | 0.09 | 56.9 |
Black | 0.10 | 56.5 |
Yellow | 0.13 | 56.6 |
Purple | 0.18 | 57.6 |
Pink | 0.13 | 54.1 |
Light Blue | 0.16 | 54.9 |
